U.S.Federal Specification Turnbuckles (FF-T791b)
Product |
Size(Diameter |
Acerage |
Approx. Weight Each(Ibs) Work Load Limitpounds |
||||||
Eyes and/ |
Jaw& |
Jaw& |
Stub |
Bodies |
Hook& |
Eye&Eye |
|||
YS01B01 |
1/4”×4” |
8-1/4 |
0.3 |
0.3 |
0.4 |
0.29 |
0.17 |
400.00 |
500.0 |
YS01B02 |
5/16”×41/2” |
9-9/16 |
0.5 |
0.35 |
0.58 |
0.46 |
0.25 |
700.00 |
800.0 |
YS01B03 |
3/8”×6” |
11-7/8 |
0.75 |
0.82 |
0.93 |
0.75 |
0.3 |
1.00 |
12.0 |
YS01B04 |
1/2”×6” |
13-5/16 |
1.50 |
1.62 |
1.68 |
1.36 |
0.55 |
1.50 |
2.2 |
YS01B05 |
1/2”×9” |
16-5/16 |
1.75 |
1.82 |
1.85 |
1.69 |
0.74 |
1.50 |
2.2 |
YS01B06 |
1/2”×l2” |
19-5/16 |
2.18 |
2.19 |
2.20 |
2.0 |
0.93 |
1.50 |
2.2 |
YS01B07 |
5/8“×6” |
15-1/2 |
2.63 |
2.59 |
2.82 |
2.15 |
0.91 |
2.25 |
3.5 |
YS01B08 |
5/8“×9” |
18-1/2 |
3.00 |
3.01 |
3.25 |
2.7 |
1.2 |
2.25 |
3.5 |
YS01B09 |
5/8”×12” |
21-1/2 |
3.25 |
3.50 |
3.75 |
3.22 |
1.5 |
2.25 |
3.5 |
YS01B10 |
3/4”×6” |
17 |
3.75 |
4.25 |
4.68 |
3.25 |
1.3 |
3.00 |
5.2 |
YS01B11 |
3/4“×9” |
20 |
4.50 |
5.00 |
5.38 |
4.0 |
1.7 |
3.00 |
5.2 |
YS01B12 |
3/4”×12” |
23 |
5.75 |
5.75 |
6.12 |
4.65 |
2.12 |
3.00 |
5.2 |
YS01B13 |
3/4”×18” |
29 |
7.00 |
7.25 |
7.25 |
6.12 |
2.93 |
3.00 |
5.2 |
YS01B14 |
7/8”×6” |
18 |
- |
- |
- |
4.75 |
2.0 |
4.00 |
7.2 |
YS01B15 |
7/8”×12” |
24-5/8 |
8.38 |
8.88 |
9.36 |
6.67 |
3.0 |
4.00 |
7.2 |
YS01B16 |
7/8”×18” |
30-5/8 |
10.25 |
10.60 |
11.44 |
8.75 |
4.12 |
- |
7.2 |
YS01B17 |
1”×6” |
20-5/8 |
- |
- |
- |
6.41 |
2.5 |
5.00 |
10.0 |
YS01B18 |
1”×12” |
26-5/8 |
11.25 |
12 |
12.88 |
8.9 |
3.86 |
5.00 |
10.0 |
YS01B19 |
1”×18” |
32-5/8 |
14.00 |
14.75 |
16.1 |
11.7 |
5.5 |
5.00 |
10.0 |
YS01B20 |
1”×24” |
38-5/8 |
17.00 |
17.75 |
18.6 |
14.3 |
7 |
- |
10.0 |
YS01B21 |
1-1/4”×6” |
20 |
- |
- |
- |
10.4 |
4 |
- |
15.2 |
YS01B22 |
1-1/4”×12 |
29-7/8 |
19.00 |
21.2 |
23.6 |
14.2 |
5.93 |
- |
15.2 |
YS01B23 |
1-1/4”×18” |
35-7/8 |
24.10 |
26. |
26.6 |
18 |
8 |
- |
15.2 |
YS01B24 |
1-1/4”×24” |
41-7/8 |
25.00 |
28.7 |
31.2 |
21.8 |
10 |
- |
15.2 |
YS01B25 |
1-1/2”×6” |
22-1/2 |
- |
- |
- |
15.4 |
5.8 |
- |
21.4 |
YS01B26 |
11/2”×12” |
32-3/8 |
27.00 |
31.1 |
35.5 |
20.5 |
8.4 |
- |
21.4 |
YS01B27 |
1-1/2”×18” |
383/8 |
31.20 |
36.4 |
40.7 |
26.2 |
11.5 |
- |
21.4 |
YS01B28 |
1-1/2”×24” |
443/8 |
38.20 |
44.2 |
47.6 |
31.4 |
14.1 |
- |
21.4 |
YS01B29 |
1-3/4”×6” |
- |
- |
- |
- |
22.7 |
8.75 |
- |
28.0 |
YS01B30 |
13/4”×18” |
413/4 |
45.00 |
48.8 |
52.4 |
- |
- |
- |
28.0 |
YS01B31 |
1-3/4”×24” |
473/4 |
58.00 |
60. |
64. |
43.9 |
19.5 |
- |
28.0 |
YS01B32 |
2”×6” |
- |
- |
- |
- |
31.5 |
12.5 |
- |
37.0 |
YS01B33 |
2”×24” |
513/4 |
90.00 |
102. |
115. |
60.3 |
27.5 |
- |
37.0 |
YS01B34 |
2-1/2”×6” |
- |
- |
- |
- |
60.8 |
27.0 |
- |
60.0 |
YS01B35 |
